Stuart Turner Aquaboost IBolt 0508 Horizontal Multistage Booster Pump 240v

Name: Stuart Turner Aquaboost IBolt 0508 Horizontal Multistage Booster Pump 240v
Brand: Stuart Turner
SKU: 47379
Price: 1226 GBP
Availability: InStock

SKU

47379

MRRP £1,915.00 + VAT Our price £1,226.00 (+ VAT) Incl. VAT: £1,471.20

BEST ONLINE PRICES

FREEPHONE 0800 112 3134 if you've seen it cheaper.

Order within

Hours

Mins

Secs

for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

Overview & Spec

Stuart Turner Aquaboost IBolt 0508 Horizontal Booster Pump 240v

The Aquaboost IBolt pump range features a horizontal multistage pump controlled by an air-cooled variable speed frequency inverter mounted directly on the pump motor.

Features:

Flow rates up to 8m3/hr
Maximum head 9.2 bar
Dry run protection
304 stainless steel pump
Stainless steel/brass discharge fittings
Nickel plated WRAS approved ball valves
Air cooled inverter
BMS volt free contacts
Hydraulic kit, base plate and anti-vibration mount options available

Application:

Cold water pressure and flow boosting in a range of domestic, commercial and industrial applications

More Information
SKU	47379
Manufacturers	Stuart Turner
Manufacturers Warranty	2 Years
GTIN	5050400473794
Weight	24.0 Kg
Dimensions	320mm (h) x 567mm (d) x 176.5mm (w)
Inlet Dimension	1 1/4" BSP
Discharge Dimension	1" BSP
Full Load Current (FLC)	7.3 A
Voltage	240V 1Ph 50Hz
Max Flow	8m3/hr
Max Head	92m
Max Temperature	40°C
Material	Stainless Steel
Seal Type	EPDM / Carbon / Ceramic
Impeller Material	Stainless steel
