KSB AMA-Porter 524 ND Submersible Waste Water Pump without Floatswitch 415v
BEST ONLINE PRICES
FREEPHONE 0800 112 3134 if you've seen it cheaper.
* Available where Guaranteed Stock Icon Appears Below
KSB AMA-Porter 524 ND Submersible Waste Water Pump without Floatswitch 415v - 39100420
The KSB Ama Porter 524 ND (39100420) are stongly built DN50 three-phase submersible pumps with Free-Flow impeller technology that is capable of pumping wastewater containing solid matter. This model is an Ama Porter ND version, this means that they use three-phase power (10m cable) and are manual operation (without a float switch).
The KSB Ama Drainer series are commonly used in pumping stations, domestic waste water, Waste water transport and the draining of pits, shafts, etc.
high operating reliability, even under tough operating conditions due to generously sized motor and thermal overload protection
- long service life with shaft made of corrosion-resistant stainless steel and one or two bi-directional mechanical seals
- trouble-free operation, resistance to clogging by coarse particles is prevented by large free passage (vortex impeller)
- stationary pump sets easy to install and remove with automatic, bolt-free connection; leakage prevented by elastic sealing elements
- ease of service with wetted bolts made of stainless steel which are easy to undo even after years of operation
Features include:
- active hydraulic component; free flow impeller
- 10m power cable
- impeller diameter: 170mm
- free passage: 40mm
- power cable: (mm2): 7G1.5
| SKU | 39100420 |
|---|---|
| Manufacturers | KSB |
| Manufacturers Warranty | 2 Years |
| Weight | 54.0 Kg |
| Connection Type | 50mm Flanged |
| Motor Size | 4.2kW |
| Full Load Current (FLC) | 9A |
| Voltage | 415V 3Ph 50Hz |
| RPM | 2900rpm |
| Cable Length | 10 Metres |
| Max Flow | 48m3/hr |
| Max Head | 34m |
| Max Temperature | 40°C |
| Material | Cast Iron |
