DAB FEKA FXV 20.07 TNA Submersible Wastewater Pump 415v

SKU
60191209
MRRP £1,073.00 + VAT Our price £752.00 (+ VAT) Incl. VAT: £902.40
Order within
Hours
Mins
Secs
for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

DAB FEKA FXV 20.07 TNA Submersible Wastewater Pump 415v - 60191209

Feka FXV is a submersible pump for draining sewage water in commercial building service. It is certified for the European Union standard EN 12050-1 which applies to sewage lifting containing faecal material in buildings and construction sites. Pump suitable for fixed installations with a coupling device or mobile if placed directly on the bottom of the tank. High-performance super vortex impeller with solid handling up to 50 mm or 60 mm. The pump is suitable for liquid with solids and long fibers in suspension. The reduced overall dimensions and the outlet ports both flanged and threaded make it ideal for replacements. Designed for quick maintenance thanks to a constructive solution that provides easy access to the main components of the pump. Automatic versions with power up to 1,5 kW. ATEX version available for use in potentially explosive environments. (ATEX certifications: II2G Ex db k IIB T4 or IEC EX: Ex db IIB T4 Gb).

CONSTRUCTION FEATURES OF THE PUMP Pump body and impeller in cast iron. Motor shaft in AISI 304 stainless steel. Double mechanical seal in SiC-SiC/SiC-C in oil chamber not in contact with the pumped liquid, independent of the direction of rotation. Delivery port both flanged and threaded.

CONSTRUCTION FEATURES OF THE MOTOR Available in single-phase asynchronous motor (MA / MNA versions) and three-phase motor (TNA versions). Rotor mounted on lubricated bearings. Continuous operation in S1 with the motor completely immersed. Dry running for a maximum time of 10 minutes. Over-temperature sensors in the motor windings with intervention threshold at +130°C. Quick-bonded resin-bonded cable gland, 07RN8-F power cable. Single-phase versions with integrated capacitor, available with float for automatic operation (MA) with powers up to 1,5 kW. In the three-phase motors the over-temperature sensor connection is responsibility of the user.



More Information
SKU 60191209
Weight 35.0 Kg
Dimensions 464mm (h) x 307mm (dia)
Manufacturers DAB
Manufacturers Warranty 2 Years
Material Cast Iron
Impeller Material Cast Iron
Connection Type 2 Inch Flanged
Voltage 415V 3Ph 50Hz
Max Flow 29m3/hr
Max Head 12m
Full Load Current (FLC) 2.4A
Motor Size 1.4kW
Cable Length 10m
Immersion Depth 20m
