Calpeda NM 50/25B/C Flanged End Suction Pump 415V

Name: Calpeda NM 50/25B/C Flanged End Suction Pump 415V
Brand: Calpeda
SKU: NM50-25BC
Price: 2565 GBP
Availability: InStock

SKU

NM50-25BC

MRRP £3,664.00 + VAT Our price £2,565.00 (+ VAT) Incl. VAT: £3078.00

BEST ONLINE PRICES

FREEPHONE 0800 112 3134 if you've seen it cheaper.

Order within

Hours

Mins

Secs

for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

Overview & Spec

Calpeda NM 50/25B/B Flanged close coupled end suction centrifugal pump with 15.0kW (20.0HP) 415V 3Ph 50Hz Motor - NM50-25BC

Calpeda NM flanged end suction close-coupled centrifugal pumps have an electric motor with shaft directly connected to the pump.

These pumps are suitable for the following applications:

Clean liquids without abrasives, which are non-aggressive for the pump materials (solids content up to 0.2%)
Mains water supply
Heating, air conditioning, cooling and circulation
Civil and industrial applications
Fire fighting applications
Irrigation

More Information
SKU	NM50-25BC
Manufacturers	Calpeda
Manufacturers Warranty	1 Year
Weight	132.0 Kg
Dimensions	695mm (d) x 405mm (h) x 320mm (w)
Inlet Dimension	65mm Flanged
Discharge Dimension	50mm Flanged
Motor Size	15.0 kW
Full Load Current (FLC)	27.3A
Voltage	415V 3Ph 50Hz
Max Flow	69m3/hr
Max Head	69m
Max Temperature	90°C
Material	Cast Iron
