ABS JS 12 114 Submersible Sludge Pump Without Floatswitch 415v

SKU
J51C56231111112
MRRP £3,153.00 + VAT Our price £1,893.00 (+ VAT) Incl. VAT: £2,271.60
Order within
Hours
Mins
Secs
for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

ABS JS 12 114 Submersible Sludge Pump Without Floatswitch 415v - J51C56231111112

The JS 12 submersible sludge pump is excellent for pumping sludge and water mixed with solids. The pump has a slim design and low weight, which makes it easy to move and easy to handle. It can run without risk of overheating the motor or sludge clogging.

Features:

  • Plug-and-pump installation without having to worry about overheating
  • Clog-free pumping with free-flow vortex impeller and pump volute
  • High wear resistance ensures years of cost-efficient pumping
  • Slim design and low weight make the pump easy to move and handle
  • Serviceability with modular design
  • 114mm impeller diameter requires half motor or more submersed for continuous duty (pump can operate lying down)
  • Maximum submergence - 20 metres
  • Maximum temperature of pumped medium at max power input and continuous duty 40°C

Shaft Seal:

Double mechanical seal in oil bath.

  • Primary seal: Silicon carbide on silicon carbide
  • Secondary seal: Silicon carbide on silicon carbide

Discharge Connections:

  • 2" (standard), 2 ½", 3" hose connections
  • 2", 2 ½", 3" B.S.P. threaded connections

**PLEASE NOTE THAT A DISCHARGE CONNECTION IS NOT PROVIDED WITH THIS PUMP AND MUST BE PURCHASED SEPARATELY.**

More Information
SKU J51C56231111112
Manufacturers ABS
Manufacturers Warranty 1 Year
Weight 18.0 Kg
Dimensions 600mm (h) x 305mm (d)
Motor Size P2 = 0.9kW
Full Load Current (FLC) 5.5A
Voltage 415V 3Ph 50Hz
RPM 2770rpm
Cable Length 20 metres
Max Flow 32m3/hr
Max Head 12m
Max Temperature Max temperature of pumped medium at max power input and continuous duty 40 ºC
Material Aluminium
Impeller Material Nodular Cast Iron
