40mm (40NB) Flanged PN16 EPDM Untied Rubber Expansion Joint Set (x2) for Heating Systems

SKU
RBJR040PN16130
MRRP £157.00 + VAT Our price £130.00 (+ VAT) Incl. VAT: £156.00
Order within
Hours
Mins
Secs
for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

Designed to accommodate vibration the EPDM D Type single sphere expansion joint is suitable for hot and cold water, LTHW and primary systems

Flanged Untied Expansion Joints require the pipework to be securely anchored and guided for safe and correct operation

If there are high levels of vibration/ pressure at the pumps location then it is advised that tied expansion bellows are used and were working pressures are over 10BarG then tied units are required regardless of fixing points in the pipeline

Max Operating Conditions:

  • 16BarG @ 80oC
  • 9BarG @ 105oC

Minimum Operating Temp: -20oC

Test Pressure: 24BarG @ Ambient Temp

Bellow Length 130mm face to face

Construction Materials

  • Inner Tube: EPDM Compound
  • Reinforcement: Nylon® textile cord
  • Cover: EPDM Compound
  • Flanges: S235 JR Carbon Steel Zinc Plated, drilling according to BS4504/EN1092
  • Tie Bars (if fitted): Carbon Steel
  • NOT Suitable for secondary domestic hot water

    More Information
    SKU RBJR040PN16130
    Weight 8.0 Kg
    Dimensions 130mm length face to face
    Manufacturers Anchor
    Material Carbon Steel
    Max Pressure 16BarG @ 80oC
    Max Temperature 105oC @ 9BarG
    Connection Type 40mm Flanged
    Suitable For Heating Yes
